Advanced NetFlow Traffic Analysis

Most engineers implementing NetFlow or IPFIX know how to get started.  Where they sometimes stumble is in the area of a properly structured export with well thought out relationships between the templates. Today I want to provide an good example.

This  post on building a NetFlow Cache and exporting IPFIX is pretty deep. For this reason, my prior post on Exporting NetFlow or IPFIX   really should be reviewed first.  A flow cache entry in a router or switch is built using the first packet between two hosts and the cache table is maintained for all active connections (i.e. flows).   When a packet comes into the device, its tuple is compared to existing entries in the cache table.  A match of the key fields triggers a flow entry update where packet, byte counts and perhaps other fields are incremented and updated. Packets that don’t match a flow entry are compared to policy (e.g. firewall or ACL rules) and are ultimately dropped or used to create new cache entries.  Flow entries are exported to a flow collector periodically based on timers (I.e. Active Timeout) or flow behaviors.
